Champion Door Type High Temperature Dishwasher with Booster & Ventless Heat Recovery, 40 Racks /Hour

ITEM#: DH-6000-VHR

Product Overview

The Champion Door-Type High Temperature Dishwasher with Booster & Ventless Heat Recovery delivers powerful sanitizing performance with unmatched energy efficiency. Featuring a built-in booster heater, ventless heat recovery system, and smart touchscreen interface, this dishwasher provides superior cleaning results while significantly reducing water, energy, and ventilation costs.

Key Features
  • Ventless Heat Recovery System: Captures exhaust heat and steam to preheat rinse water, reducing energy use and eliminating the need for external venting.
  • Built-In Booster Heater: Ensures a consistent 180°F final rinse, meeting high-temperature sanitization standards.
  • High-Capacity Cleaning: Processes up to 40 racks per hour with just 0.73 gallons of water per rack, ensuring superior cleaning with minimal resource consumption.
  • Advanced HMI Touchscreen Interface: Provides intuitive visual alerts, multilingual operation guidance, and easy access to system functions.
  • On-Board Service Diagnostics: Detects and displays machine faults for fast troubleshooting and minimal downtime.
  • Rinse Sentry Technology: Extends the rinse cycle automatically until the booster reaches sanitizing temperature, guaranteeing proper sanitation every cycle.
  • Programmable Sleep Mode: Shuts off internal heaters after a user-defined idle period to conserve energy during off hours.
  • Door Interlock System: Locks the door during the vent fan cycle to maximize heat recovery and minimize steam in the dishroom.
  • Automated Delime Function: Cleans the interior with a customizable alert schedule based on water quality and usage.
  • Dual NSF Certification: Meets NSF standards as both a stationary rack dishwasher and pot/pan washer, offering versatile cleaning performance.
  • High-Efficiency Pump System: Equipped with a 2 HP wash pump for strong water pressure and efficient cleaning results.
  • Automatic Drain Valve: Heavy-duty, gear-driven stainless and brass valve automatically drains the wash tank when power is off.
  • Vent Fan, Detergent, and Rinse Aid Signals: Pre-configured for seamless connection to accessory systems.
  • Four Wash Cycles: Users can select 1-, 2-, 4-, or 6-minute wash cycles based on soil level or load type.
  • Cycle Counter: Tracks total cycles since installation for maintenance planning and performance tracking.

Note: Voltage must be specified when placing the order to ensure correct configuration and installation.

Ideal for restaurants, hotels, and institutional kitchens, this dishwasher provides cleaner dishes, a cooler workspace, and long-term operational savings all backed by Champion’s industry-leading quality and reliability.

Retail Price:

Request a Quote

Why is the price hidden?

Specifications

Item NumberDH-6000-VHR
Exterior Width34 Inches
Exterior Depth31.65 Inches
Exterior Height69 Inches
Number of Racks40 Racks / Hour
Wash Tank Capacity10 Gallon
Motor Horsepower2 HP
Gallon Per Rack0.73 Gallon Per rack
High or Low TempHigh Temp
Amps48-50 Amps
Voltage208 Volts
Hertz60 Hz
Phase3 Phase

Shipping Options

Available for <br/>Delivery

Available for
Delivery

Free In-Store Pick Up. T&C Apply. <a href="https://nellacutlery.myshopify.com/pages/shipping-pick-up">Click Here</a> For Info

Free In-Store Pick Up. T&C Apply. Click Here For Info

Product Overview

The Champion Door-Type High Temperature Dishwasher with Booster & Ventless Heat Recovery delivers powerful sanitizing performance with unmatched energy efficiency. Featuring a built-in booster heater, ventless heat recovery system, and smart touchscreen interface, this dishwasher provides superior cleaning results while significantly reducing water, energy, and ventilation costs.

Key Features
  • Ventless Heat Recovery System: Captures exhaust heat and steam to preheat rinse water, reducing energy use and eliminating the need for external venting.
  • Built-In Booster Heater: Ensures a consistent 180°F final rinse, meeting high-temperature sanitization standards.
  • High-Capacity Cleaning: Processes up to 40 racks per hour with just 0.73 gallons of water per rack, ensuring superior cleaning with minimal resource consumption.
  • Advanced HMI Touchscreen Interface: Provides intuitive visual alerts, multilingual operation guidance, and easy access to system functions.
  • On-Board Service Diagnostics: Detects and displays machine faults for fast troubleshooting and minimal downtime.
  • Rinse Sentry Technology: Extends the rinse cycle automatically until the booster reaches sanitizing temperature, guaranteeing proper sanitation every cycle.
  • Programmable Sleep Mode: Shuts off internal heaters after a user-defined idle period to conserve energy during off hours.
  • Door Interlock System: Locks the door during the vent fan cycle to maximize heat recovery and minimize steam in the dishroom.
  • Automated Delime Function: Cleans the interior with a customizable alert schedule based on water quality and usage.
  • Dual NSF Certification: Meets NSF standards as both a stationary rack dishwasher and pot/pan washer, offering versatile cleaning performance.
  • High-Efficiency Pump System: Equipped with a 2 HP wash pump for strong water pressure and efficient cleaning results.
  • Automatic Drain Valve: Heavy-duty, gear-driven stainless and brass valve automatically drains the wash tank when power is off.
  • Vent Fan, Detergent, and Rinse Aid Signals: Pre-configured for seamless connection to accessory systems.
  • Four Wash Cycles: Users can select 1-, 2-, 4-, or 6-minute wash cycles based on soil level or load type.
  • Cycle Counter: Tracks total cycles since installation for maintenance planning and performance tracking.

Note: Voltage must be specified when placing the order to ensure correct configuration and installation.

Ideal for restaurants, hotels, and institutional kitchens, this dishwasher provides cleaner dishes, a cooler workspace, and long-term operational savings all backed by Champion’s industry-leading quality and reliability.
